2025 was a year of rapid development for Sunyu Photonics. We achieved remarkable results in the silicon photonics testing field. We would like to thank every customer for their trust and support.
Annual Highlights
- First equipment sales breakthrough: Successfully completed the key leap from 0 to 1, marking initial market recognition of our products;
- Completed automated testing R&D for wafer-level Near-Packaged Optics (NPO): Breakthrough in opto-electronic collaborative automated testing technology under NPO scenarios, laying the foundation for mass production testing of high-density packaged optical devices;
- Singapore laboratory upgraded: Introduced advanced testing equipment, expanded VCSEL wafer-level testing services and other service capabilities, improving overall technical service level;
- Navigo software achieved major version iteration: Completed functional upgrades and performance optimization from V1.0 to V2.0, significantly improving system stability and automation;
- Obtained 5 technology patents: Built intellectual property barriers in core technology areas such as optoelectronic testing and data processing, enhancing technological moat.
Technology Innovation
In 2025, we achieved major breakthroughs in technology R&D:
- Successfully developed a new generation of edge-coupling testing system
- Launched testing solution supporting 12-inch wafers
- Upgraded Navigo software to version 2.5
- Established comprehensive testing service process
Looking Ahead to 2026
In the new year, we will continue to focus on silicon photonics testing and provide better products and services for our customers. In 2026, we will:
- Complete NPO near-packaged optics mass production automated testing
- Continue to grow the Singapore team while formally entering the Chinese market, starting regional business expansion.
- Launch more customized solutions
- Expand global partner network
Once again, thank all customers and partners for your support and trust! Let's create a brilliant 2026 together!
